Control cabinet service interface uses half the space

The service interface allows authorised persons to gain direct access to defined processes from outside by connecting diagnostic hardware via a data cable or optional power cable. The FrontCom Vario provides easy access to the control system/PC and electronics, whether the user is reading out production data, troubleshooting on the PLC, modifying configuration and programming or performing maintenance work.

The device integrates several functions in a single frame measuring 67x133mm. The installation cut-out is compatible with the 52x91mm market standard, while the housing is impact-resistant and IP65 rated. Markings can be attached to both the inside and outside of the interface. For security, the service interface features a closing knob and lock variant which only grants access to authorised personnel. To allow users to easily access the control system/PC and electronics, the FrontCom Vario features a magnetic cover which fixes to the metal cabinet wall when open. With more than 5,000 combinations, the device offers users a future proof solution.
