Oscilloscope FFT functions examined in webinar
FFT and Spectrum Analysis with an Oscilloscope is the title of a webinar to be hosted by Teledyne LeCroy on April 1.
This webinar will describe the FFT function of an oscilloscope in detail. We will cover the settings of the oscilloscope that will affect the FFT result, and how the spectrum analyser function can help with measurements in the frequency domain.
Topics to be covered in the webinar include overview of the FFT, approximation procedures, representation of the FFT, Windowing functions and spectrum analyser software.
The presenter is Jeremy Gilbert, Applications Engineer at Teledyne LeCroy.
