Würth Elektronik presents optical sensors for object recognition

These compact modules contain both emitters and detectors for infrared light at 940nm wavelength. A special feature: The Würth Elektronik sensors filter out visible light up to 800nm, rather than just up to 700nm as is the case for many other sensors of this type available on the market. So, they are less susceptible to errors occurring under artificial lighting.

The sensor in the 4-SMD gullwing standard housing measures 2.7 × 3.4 × 1.5mm without contacts. It is designed for close range, typically at a distance of 1 mm and serves as a simple touch switch, for example under a glass plate. The second compact SMD sensor, with its lower beam angle and measuring 2.0 × 1.6 × 0.75mm, can detect at a greater distance up to 10mm, making it more robust against crosstalk than a simple touch switch, e.g., when used under glass. Both sensors offer an analog output and low energy consumption. Possible applications include optical encoders, switches and interlocks, as well as object detection or touch applications.

The Würth Elektronik infrared sensors are now available from stock without a minimum order quantity. Developers can receive free samples.
