AKM begins mass production of ultra-thin Hall element

It achieves an 85% reduction in volume compared to the previous model of HQ0811 in the high-sensitivity HQ series. It is expected that HQ0A11 will contribute to improved performance in smartphone camera modules, small robots, and other applications.

HQ0A11 is smaller and thinner than the HQ0811 (1.6 x 0.8 x 0.38mm), which was previously the smallest and thinnest high-sensitivity Hall element. It also has an approximately 16% better S/N (signal-to-noise) ratio, which directly correlates to position detection accuracy, than HQ0811, which previously had the highest S/N performance in the HQ series. Hall elements are used to detect magnetic fields (magnetic flux density). AKM started its Hall element business in 1974 with the development of sensors for automobile airbags. While advancing its development and manufacturing expertise to meet evolving market needs, AKM has shipped over 50 billion Hall sensors to date, including both Hall elements and Hall ICs.

Hall elements are often used for the position detection that is needed for image stabilisation and autofocus in smartphone cameras. The demand for enhanced functionality and higher-resolution capture in cameras requires an increased component count within the same (or smaller) form factor, creating a growing need for ultra-compact products that enable high-density component mounting in a limited space. HQ0A11 achieves the highest S/N performance among AKM products for position detection by leveraging the characteristics of InAs. Its position detection accuracy is over 3.5 times higher than that of the HG0C11, a GaAs (gallium arsenide) Hall element which has been a mainstay product for camera modules. As such, HQ0A11 can significantly reduce the lens-shake effect that often occurs with smartphone cameras, especially with telephoto lenses.

AKM will continue to leverage its proprietary compound semiconductor and packaging technology in order to further contribute to the miniaturisation and higher performance of electronic products such as smartphones, small motors for robots, and many other applications.

Features of HQ0A11

The smallest and thinnest package size among AKM’s InAs Hall elements

AKM's smallest and thinnest package size of 0.8 x 0.4 x 0.23mm enables increased flexibility in design for applications with limited space for mounting, such as smartphone camera and lens modules, etc.

High S/N performance enables more precise lens position control

S/N performance over 3.5 times higher than the HG0C11 Hall element, the present mainstay product for camera modules. The HQ0A11’s high sensitivity also makes it suitable for applications such as paper thickness detection.

Stable operation

Since the Hall element does not contain magnetic materials, there is a low risk of failure and malfunction due to adsorption or changes in magnetic field strength. This allows for stable operation even in environments such as the vicinity of motors.
