Precisely space PCBs with SMPM bullet adaptor for blindmate applications

This microminiature product series provides a versatile connectivity solution for board‐to‐board and cable‐to‐board designs with reliable electrical performance up to 40GHz. This new bullet adaptor allows for a minimum PCB spacing of 9.75mm and is ideal for IoT, military and test and measurement applications.

SMPM bullet adaptors are machined from beryllium copper with gold plating for high‐frequency electrical performance. When used in conjunction with SMPM PCB connectors, this three‐piece design is well‐suited for blindmate situations. This series is available in straight and right‐angle configurations with cable solutions optimised to meet the frequency limits of high‐frequency cables, and PCB options with surface mount, through‐hole leg or edge mount terminations.

This series is designed for a wide range of precision and miniaturised designs including antennas, handheld radios, military communication systems and instrumentation and measurement equipment.
