WM Series IP45 Rated, Outdoor, Wall Mount, True On-Line UPS System from Powersolve

WM Series units provide up to 1.5kVA of constant, reliable power from an input voltage of 115 or 230VAC and offer a range of selectable outputs from 100 to 240VAC. Powersolve has used an online double-conversion topology to provide a high integrity AC power source with zero transfer time to battery on mains failure conditions. The design also protects the load against noise and transients.

Up to four battery strings can be incorporated giving 43 minutes hold up at 1.5kVA and over 2 hours at 600VA. 10 year life batteries are also available as an option.

WM Series units incorporate many standard and optional features designed to make them easy to use and come ready for use “straight out of the box”. Remote emergency power-off is incorporated, making WM series units ideal for hazardous environments.

A backlit LCD display provides information on a number of parameters including input voltage, output voltage and frequency, battery voltage and load.

As standard, each unit is supplied with Xprotect software and covers all Windows® based platforms. Xprotect offers all of the functionality of standard shutdown packages with some additional features for remote monitoring and control.
Monitoring is achieved locally via RS232 or remotely via a connected network.

WM1500 systems are specified for use over the operating temperature range of
-10 ºC to 40ºC. They also meet all current and appropriate EMC and safety requirements.
