Ultra-compact convection-cooled 125W power supply offers flexibility in four formats

Despite its small size, the full 125W output power is delivered with convection cooling only so there is no need for a fan to achieve full power with these units.

These units offer single-output voltages ranging from 12 to 48V and have both Class I and Class II protective earth variants.

Offering high efficiencies of up to 92% with low standby current consumption these units also feature a range of protection circuits as well as a built-in EMI filter.

This unique design generates less wasted heat, reducing the need for forced air cooling, decreasing AC power consumption, increasing reliability, and maximising its economy of operation.

Power supply features:

• 125W AC-DC
• High efficiency of up to 92%
• Low standby power consumption </=0.3W
• Wide input voltage range 85 to 264VAC
• Also supports DC-DC (input 120 to 370VDC)
• Built-in EMI filter
• Output voltage adjustable (-10%W, 0.25W dummy load)
• Open frame dimensions 2.00x3.00x1.16”
• 3000VAC input to output reinforced insulation
• Protection type Class I or Class II
• Leakage current: 300µA at 264VAC
• Operating temperature of -40°C to +85°C
• Operating altitude of 5000m
• Conformal coating option
• Three-year warranty

As usual with products from N2 Power, if you can’t find your preferred output voltage, we can easily modify standard PSUs to meet client-specific requirements.

Our product specialists are on hand to assist with product selection and guide you through the design cycle. We offer technical and commercial support. Please contact us to arrange samples for evaluation, a quote, to discuss your application or request more information.
