Meeting sophisticated power requirements

26th January 2016

MTM Power GmbH

Joe Bush

0 0

Datasheet

MTM Power has introduced the HSA50 DIN-rail module, designed as a universal compact power supply with AC (90-264V AC) and DC (120-340V DC) wide input range for use under rough environmental conditions. The modules are available with single outputs of 12V, 24V and 48V.

The ambient temperature range is -25 to +70°C and the dimensions are 42x115x75mm. They comply with protection class II, the Low Voltage Directive as well as the up to date EN standards regarding CE conformity. Moreover, the modules are VDE as well as UL/cUL, UL 508 approved.

Further to the standard features, this module offers additional technical optimisations for the use in switching cabinets. The case design enlarges the heat dissipating surface of the power supply and in combination with the high efficiency, leads to an optimised heat emission. Therefore, the device remains cool even with higher ambient temperatures and provides a high reliability. In case of overload, a regulation concept has been used which ensures a safe start even under most difficult load cases.

The regulation allows a maximum over current of up to 1.6 times of the nominal current with decreasing output voltage. By this bent U-I-characteristic curve it is guaranteed that the device is not too strongly stressed thermally in case of overload, and that even with regularly occurring overloads the lifetime is not reduced. As a standard, the output voltage is monitored by a power good signal. The module can optionally be delivered with parallel and redundancy operation.
