Magnachip's 150V MXT MOSFET for Light Electric Vehicles

3rd January 2023
Sheryl Miles
0

Magnachip announces the company has launched its 8th-gen 150V MXT Metal-Oxide-Semiconductor Field-Effect Transistor (MOSFET)1 optimised for Light Electric Vehicle (LEV) motor controllers and battery management systems (BMSs).

Energy efficiency plays a critical role in electric devices when it comes to power consumption and product stability. This newly-released MOSFET (MDT15N054PTRH) features Magnachip’s 8th-gen trench MOSFET technology to lower RDS(on)2 by 28%, as compared to the previous generation. Based on the enhanced design of the core cell and termination, a high figure of merit can be achieved and an increase in the total gate charge3 can be avoided.

MDT15N054PTRH is available in a surface mount device TO-Leadless (TOLL) package to reduce product size and improve heat dissipation. The energy efficiency is also significantly enhanced by fast switching, while enabling high power density. In addition, a guaranteed operating junction temperature from -55°C up to 175°C and a high level of avalanche ruggedness help the new MXT MOSFET to exceed the performance requirements of LEV motor controllers and BMSs.

“Beginning in 2008 we have released more than 40 MOSFET products for motor controllers and battery management systems and, since 2017, most of them have been made for LEV applications,” said YJ Kim, CEO of Magnachip. “As a provider of high-performance MOSFETs, Magnachip will continue to deliver innovative solutions that meet the sophisticated requirements of the market.”

Product features

  • low RDS(on) and switching loss
  • great heat dissipation performance
  • guaranteed operating junction temperature from -55°C up to 175°C
  • a wide range of applications, such as LEV motor controllers and BMSs and switch mode power supplies for various consumer electronics



1 MXT MOSFET (Magnachip eXtreme Trench MOSFET): Magnachip’s cutting-edge product portfolio

of trench MOSFETs, including low and medium voltage MOSFETs

2 RDS(on): On resistance, the resistance value between the drain and the source of MOSFETs during

on-state operation

3 Total gate charge (Qg): the amount of charge required to be injected into the gate electrode to turn

ON (drive) the MOSFET
