Industrial PC Power Supply with strong +12V rail for latest processors

29th August 2024
Sheryl Miles
0

Bicker Elektronik presents the new BEA-551K, a powerful 500W industrial PC PSU for stable ATX power supply of motherboards with the latest processor generation Intel Core.

These CPUs have a highly dynamic power consumption with sometimes extreme jumps in performance within a very short time. Thanks to a strong +12V single rail with 36A and the excellent control behaviour for all output voltages, the robust switching power supply is optimally designed for the new requirement profiles of modern processors. The BEA-551K thus guarantees excellent control stability, even with demanding CPU power levels (PL2).

Robust design for demanding industrial applications

The BEA-551K was developed for operation under industrial conditions. It offers an extended temperature range of –10 to +70°C and works reliably even in environments with high temperature fluctuations. The outstanding quality of the power supply is based on the use of high-quality components, such as Japanese brand capacitors of grade +105°C, which ensure a significant extension of the service life even at high operating temperatures. The robust construction, including a through-plated FR4 circuit board, ensures stable solder connections and high mechanical resilience, even under the influence of shock and vibration.

High energy efficiency and international use

The energy-saving IPC power supply with a consistently high efficiency of up to 92.5% and a standby consumption of less than 0.5W reduces energy consumption and helps to reduce operating costs. With its wide-range input of 90 to 264VAC and active power factor correction (PFC), the power supply is designed for worldwide use. In addition, the BEA-551K is certified according to the current safety standards EN/UL 62368-1 and CCC, which ensures a high level of operational safety. The precisely regulated outputs of the BEA-551K are equipped with protection functions against short circuits, overcurrent and overvoltage as standard to ensure additional operational safety. All ATX outputs (+3.3V, +5V, +12V, -12V, and +5Vsb) do not require a base load. Reliable cooling and low-noise operation

Another feature of the BEA-551K is the cooling system with a well-thought-out arrangement of the power components and optimised thermal airflow management. Equipped with a ball-bearing branded fan that is temperature-controlled and has tachometer signal monitoring, the power supply offers reliable cooling even under full load. The fan control automatically adjusts the rotation speed of the fan to the operating temperature, which minimises noise. Continuous monitoring of the fan also ensures high system availability and prevents potential failures, which is particularly important for 24/7 continuous operation in critical applications. Excellent EMC properties and high immunity to interference

The BEA-551K impresses with excellent electromagnetic compatibility (EMC) and meets the strict requirements of Class B according to EN55032:2015/AC:2016. This property makes it particularly suitable for use in industrial environments susceptible to interference. In addition, the power supply unit meets the standards EN 61000-6-2 for increased immunity to interference and EN 61000-6-4 for interference emissions in industrial environments. These properties ensure that the BEA-551K works stably and reliably even in industrial environments with strong electromagnetic interference. Durability and reliability in 24/7 continuous use

The BEA-551K was developed for continuous operation and is ideal for industrial applications where reliability and durability are crucial. It is designed for 24/7 operation and ensures a continuous and stable ATX power supply even under adverse conditions. The sophisticated circuit design and the use of first-class components ensure a particularly long service life of the industrial PC power supply. Bicker Elektronik grants a three-year guarantee on the BEA-551K, combined with long-term availability of at least five years.

All product advantages at a glance

  • 500 W Industrial PC Power Supply
  • Powerful 36A at +12V output (Single-Rail)
  • Safe power supply for the latest processors
  • High efficiency of up to 92.5%
  • No minimum load required
  • EN/UL 62368-1 / CCC
  • Ball bearing brand fan with temperature control and tachometer signal monitoring
  • Increased interference immunity
  • Wide temperature range –10...+70°C
  • High quality and reliability
  • Three years warranty
