FORTEC UK unveils the CFB800-24S56: a high-efficiency DC-DC converter for transportation and beyond

Power and efficiency optimised

The CFB800-24S56 delivers a powerful 800W of regulated output, achieving up to 90% efficiency. Its broad operational temperature range from -40°C to +100°C guarantees consistent, dependable performance even in the harshest conditions.

Built for transportation applications

Specifically crafted for transportation needs, the CFB800-24S56 features a compact full-brick design and 1500 VDC isolation between input and output. This rugged construction makes it ideal for use in railway systems, electric vehicles, and aerospace. Whether powering on-the-go systems or managing mission-critical applications, this converter provides robust power conversion and uninterrupted operation.

Unmatched safety and durability

Certified to meet rigorous safety standards, including IEC/UL 62368-1 and MIL-STD-810F for shock and vibration, the CFB800 series is built for durability. It offers an array of protective features such as input under-voltage lockout (UVLO), output over-current, over-voltage protection, and continuous short-circuit protection, ensuring long-lasting reliability even in challenging environments.

Versatility across multiple industries

Beyond transportation, the CFB800-24S56 excels in various other sectors, including base stations, motor drives, battery management systems, and charging infrastructure. Its versatility makes it the perfect solution for a wide range of power-hungry, critical applications.

Meeting the challenges of modern systems

With its cutting-edge design, high power density, and rugged construction, the CFB800-24S56 is engineered to meet the evolving power demands of today’s industries. Offering efficiency, reliability, and durability, it supports the infrastructure required to keep modern systems running smoothly.

For more information on how the CFB800-24S56 can enhance your application, contact FORTEC UK today.

Click here to view the datasheet
