Cornell Dubilier introduces low inductance DC link film capacitors

Type 944L DC Link capacitors are specifically designed for fast switching power conversion applications. Their low inductance construction and low-loss winding technology make them ideal for the next generation of high power-dense inverter and converter designs.

Applications in green energy inverter systems and level 3 EV chargers are placing greater demands on power conversion circuits that deliver more power with a smaller footprint. The CDE 944L Series was designed with these applications in mind.

The series makes use of large diameter, non-inductive windings with low-inductance internal buss connections, yielding Equivalent Series Inductance (ESL) values ranging from 10 to 15 nanohenries. Ripple current ratings of up to 90 amperes at an ambient temperature of 55°C are achieved by using low-loss polypropylene dielectric with metallised electrodes optimised for applications in fast-switching power inverters.

944L series capacitors are available in values ranging from 33 to 220µF, with voltage ratings of 800, 1000, 1200, and 1400Vdc. The series meets a 5,000-hour life test @ 85°C with rated voltage applied, yielding an expected lifetime of 100,000 hours or greater with ripple current or ambient temperature derating. The capacitors are contained in a UL94V-0-rated plastic case with integral mounting flanges for secure, vibration-resistant installation. All case sizes have an 84.5mm diameter with heights of 40, 51, and 64mm, depending upon rating. Standard termination options include M8 threaded studs or M5 threaded inserts made of tin-plated brass.

Features & Benefits:

• Designed for higher switching frequencies
• Up to 60% lower ESL (Equivalent Series Inductance)
• High ripple current
• M8 threaded stud and M5 insert termination options
• Integrated mounting flanges

Applications:

• DC Fast EV Charging
• High power solar inverters
• High power motor drives

As a franchise distributor for Cornell Dubilier, New Yorker Electronics supplies the full line of Aluminium Electrolytic Capacitors, AC Oil Filled Capacitors, DC Oil Filled Capacitors, Film Capacitors, MICA Capacitors, Ultracapacitors and Supercapacitors.
