New knitter-inductive THT common mode choke series
knitter-inductive has launched a new series of THT common mode chokes with an operating voltage of 400 V AC.
The main application of this series is the suppression of common mode interference in the AC network at operating voltages of 400 V AC.
The two designs ICSCxxxxxx22LHA61 (standard winding) and ICSCxxxxxx23LHA61 (sectional winding) of this new series stand out with their high inductance values compared with a small component size and a maximum height of only 17.5mm. This is particularly important as the trend towards smaller component sizes is clearly visible on the market.
The Common Mode Chokes are available as Standard winding and Sectional winding type. The main difference of these two winding types is the frequency of the highest attenuation, which is located on the sectional winding types at higher frequencies.
All further technical details are shown in the datasheets ICSCxxxxxx22LHA61 (standard winding) and ICSCxxxxxx23LHA61 (sectional winding), available on the Homepage www.knitter-inductive.com.
The Common Mode chokes are available with a range of inductance from 0.9mH to 43.0mH at a current rating from 0.3A to 2.0A. We also offer the possibility of tailor-made modifications without tool costs.
