SMT/SMD LEDs adapt to PCB shapes and sizes

Lumex’s surface mount RGB LEDs are distinguished by their low profile, low drive current, and IC-embedded drivers, making them adept in applications such as industrial controls, medical equipment, communications equipment, and more.

With the flexibility to adapt to various sizes and shapes of PCB designs – including hollow ring, rigid stripe, and flexible stripe – these LEDs provide versatility.

The featured Lumex LEDs are all compliant with RoHS, EU REACH, and are Halogen free.

The series includes several models:

• SMD-LX5050RGB-TR: Measuring 5.0(L)*5.0(W)*1.5(H)mm, this model features RGB full color, a 3-Channel LED driver with 8-bit PWM linear control, and a water-clear lens. It ensures low current consumption of 5mA for each color.
• SMD-LXR1204RGBC-TR: This LED, at 3.0(L)*1.0(W)*1.5(H)mm, offers a side view/right angle mount, RGB full color, and similar features in terms of driver and lens as the SMD-LX5050RGB-TR.
• SML-LXR0804RGBC-TR: With dimensions of 2.0(L)*1.4(W)*0.9(H)mm, it also features a side view/right angle mount, RGB full color, and a common anode.
• SML-LXR1003RGBC-05: This model, measuring 2.7(L)*0.8(W)*1.35(H)mm, shares similar features with the SML-LXR0804RGBC-TR, offering cutting-edge technology in a compact form.

To facilitate easy installs, Lumex provides sample code, significantly reducing development time. Furthermore, these LEDs can be integrated with Lumex’s ezDisplay controller, to offload MCUs or LED controllers.
