FIVEberry establishes broad and easy access to RISC-V technology

The FIVEberry integrates the powerful, OSM-compatible MSRZFive system-in-package (SiP) based on the single-core microprocessor RZ/Five by Renesas Electronics onto a compact evaluation board. The RZ/Five microprocessor has a RISC-V CPU core (AX45MP single) running at 1.0 GHz. “Our new baseboard supports all necessary features to make the first steps with the RISC-V CPU core,” stated Andreas Widder, Managing Director of ARIES Embedded. “This entry-level platform serves an expanded user community to develop and debug drivers and bootloaders, and even use it in prototype setups.” The RZ/Five general-purpose microprocessor units (MPUs) from Renesas are built around a 64-bit RISC-V CPU core and employ the AX45MP from Andes Technology Corporation, based on the RISC-V CPU instruction set architecture (ISA).

FIVEberry Provides Easy and Fast Design Start

The peripheral functions of the small, low-cost CPU application board FIVEberry include support for multiple interfaces, including two Gigabit Ethernet channels, two USB 2.0 channels, and two CAN channels. In addition, the baseboard offers dual A/D converter modules, making it ideal for applications such as entry-class social infrastructure gateway control and industrial gateway control.

The FIVEberry is driven by the powerful and versatile system-in-package MSRZFive from ARIES Embedded, which in the smallest size “S” concentrates extensive functionality on the board measuring just 30 by 30mm each. The module conforms to SGET’s OSM standard and offers an LCD controller. It supports 512MB to 4GB of DDR4 RAM, SPI-NOR flash and optionally 4 GB of eMMC NAND flash. The numerous interfaces include camera input (MIPI-CSI), display output (Parallel-IF), USB2.0 2ch, SD 2ch, CAN (CAN-FD), and Gigabit Ethernet 2-Channel. The temperature range starts at -25°C to +85°C and goes up to -40°C to +85°C for industrial environments.

ARIES Embedded is incorporated in Renesas' Preferred Partner Program. In the partnership with Renesas, the embedded specialists bundle their knowledge to further optimise service for customers in the field of industrial electronics.

OSM – Open Standard Module

The idea of all Open Standard Modules by SGET (Standardization Group for Embedded Technologies e. V.) is to create a new, future proof and versatile standard for small-size, low-cost embedded computer modules, combining different characteristics, such as to be completely machine processible during soldering, assembly, and testing. Further, it offers different possible packages for direct PCB soldering without a connector. In addition, it provides pre-defined soft- and hardware interfaces as well as open-source in soft- and hardware. The Open Standard Module specification allows development, production, and distribution of embedded modules for the most popular MCU32, ARM and x86 architectures. For a growing number of IoT applications, the standard helps to combine the advantages of modular embedded computing with increasing requirements regarding costs, space, and interfaces.

The FIVEberry will be available in Q3 2023.
