KIOXIA and Western Digital announce newest 3D flash memory

3rd April 2023
Kristian McCann
0

KIOXIA shares the recent developments in cooperation between, KIOXIA Corporation and Western Digital Corp. The companies announced details of their newest 3D flash memory technology.

Applying advanced scaling and wafer bonding technologies, the 3D flash memory delivers exceptional capacity, performance and reliability at a compelling cost, which makes it ideal for meeting the needs of exponential data growth across a broad range of market segments.

“The new 3D flash memory demonstrates the benefits of our strong partnership with KIOXIA and our combined innovation leadership,” said Alper Ilkbahar, Senior Vice President of Technology & Strategy at Western Digital. “By working with one common R&D roadmap and continued investment in R&D, we have been able to productize this fundamental technology ahead of schedule and deliver high-performance, capital-efficient solutions.”

KIOXIA and Western Digital reduced the cost by introducing several unique processes and architectures, enabling continued lateral scaling advancements. This balance between vertical and lateral scaling produces greater capacity in a smaller die with fewer layers at an optimized cost. The companies also developed groundbreaking CBA (CMOS directly Bonded to Array) technology, wherein each CMOS wafer and cell array wafer are manufactured separately in its optimized condition and then bonded together to deliver enhanced bit density and fast NAND I/O speed.

“Through our unique engineering partnership, we have successfully launched the eighth-generation BiCS FLASH with the industry's highest bit density,” said Masaki Momodomi, Chief Technology Officer at KIOXIA Corporation. “I am pleased that KIOXIA’s sample shipments for limited customers have started. By applying CBA technology and scaling innovations, we’ve advanced our portfolio of 3D flash memory technologies for use in a range of data-centric applications includingsmartphones, IoT devices and data centers.”

The 218-layer 3D flash leverages 1Tb triple-level-cell (TLC) and quad-level-cell (QLC) with four planes and features innovative lateral shrink technology to increase bit density by over 50%. Its high-speed NAND I/O at over 3.2Gb/s, a 60% improvement over the previous generation, combined with a 20% write performance and read latency improvement, will accelerate overall performance and usability for users.
