RM-N8MPL SMARC 2.1 module with NXP i.MX 8M Plus

Powered by the NXP ARM i.MX 8M Plus QuadLite Cortex-A53 processor, the module provides robust processing capabilities and long-term supply assurance, meeting the demands of industrial IoT, smart displays, and AI-driven systems.

The RM-N8MPL features 3GB of LPDDR4 memory and 16GB eMMC flash storage, with scalability up to 128GB, ensuring fast data processing and ample storage. Its rich peripheral I/O support includes dual MIPI-CSI2 image capture interfaces, USB 3.0 ports with OTG support, high-speed SDIO, PCIe, and CAN bus, delivering extensive connectivity for versatile application needs. Suitable for use in harsh industrial environments, it operates in a range of –40°C to 85°C, with durability against shock and vibration.

With validated Yocto 4.0 and Android 11 OS support, the RM-N8MPL ensures seamless development and integration, enabling high flexibility in software design. It also includes advanced display outputs such as HDMI, LVDS, and MIPI-DSI with up to 1,920 x 1,080 resolution at 60Hz. Graphics are powered by the GC7000UL GPU, supporting OpenGL ES, OpenCL, and Vulkan standards.

Compliant with the SMARC 2.1 specification, the RM-N8MPL offers exceptional scalability, efficient design, and future-proof compatibility for modern embedded systems, delivering a solution for industries demanding high performance, durability, and long-term availability.

RM-N8MPL features:

• NXP ARM i.MX 8M Plus QuadLite Cortex-A53 processor
• 3GB LPDDR4, 16GB eMMC on board
• Rich peripheral I/O support
• Validated with Yocto 4.0 (sumo, kernel 5.4.70) / Android 11
• Long-term supply with NXP solution
• Compliant with SMARC 2.1
• Wide-range operating temperature (–40°C~85°C)
