Anritsu has announced the extension of vector signal frequency up to 44GHz by combining Anritsu's Vector Signal Generator MG3710E with TMYTEK frequency converters.
This solution supports various tests required for developing and manufacturing 5G and satellite application products. The 6 to 20GHz and 24 to 44GHz frequency bands facilitate high-speed, low latency, wide-area coverage, and stable communications at high data rates. These bands are used by Wi-Fi 6/7, UWB (Ultra-Wideband), 5G, satellite, and other applications. With its simple, flexible, and cost-effective configuration, this solution outputs signals up to 44GHz.
As a result of this collaboration, Anritsu and TMYTEK are helping improve device quality by providing efficient test solutions for communication device development and manufacturing.
Product outline
Anritsu vector signal generator
The Anritsu MG3710E is a cost-effective vector signal generator that can be equipped with up to two RF ports in a single unit. Each port can output RF signals with a frequency range of 100 kHz to 6GHz and a maximum modulation bandwidth of 120 MHz from up to two waveform memories.
TMYTEK frequency converter up/down converter UD module
The TMYTEK UD Module is Broadband Up/Down Frequency Converter Module supporting 6GHz to 20GHz, expanding the application scenario range. Moreover, TMYTEK's frequency converters feature excellent stability and precision, assuring accurate and reliable test results.
Up/down converter UD BoX 5G
The TMYTEK UD BoX 5G is An Ultra-Broadband 5G NR mmWave Frequency Converter supporting 24GHz to 44GHz. With the built-in local oscillator (LO) from TMYTEK's phase-locked oscillator (PLO) product line to ensure excellent phase noise performance, our UD Box makes radio frequency conversion easy and flexible.
