Avalue EPS-ADS fanless rugged system

To meet different challenges, Avalue EPS-ADS provides powerful support driven by Intel 12th Gen Alder Lake-S processor with Intel UHD Graphics 770, which offer up to 32 graphics execution units (EUs) for outstanding computing performance. Using silent fanless design, passing 50G shock test and 5G vibration test, plus IP50 rating for water and dust resistance, and operating at a wide temperature range from -10°C to 55°C, EPS-ADS rugged system is sturdy and reliable, ensuring exceptional stability and reliability even in harsh environments. Equipped with a variety of I/O ports, including four 4K@60Hz display outputs, two HDMI 2.0b and two DP++ 1.4 ports, two Intel Gigabit Ethernet (2.5GbE and 1GbE) ports, three storage options (one 2.5-inch hard disk slot and two M.2 B/M slots), six COM ports (two RS232 and four RS232/422/485), and eight USB ports (two USB 2.0 and six USB 3.2), EPS-ADS offers a myriad of connectivity options to meet different application scenarios, giving users high flexibility and expandability. Furthermore, EPS-ADS fanless rugged system has a compact size, measuring 21.5cm x 20cm and only 7.5cm thick, does not take up much space and is easy to install in different places. Given its flexible I/O and fan options, Avalue EPS-ADS may be customised to users’ specific requirements and provide solutions to meet specific project requirements.

Being CE and FCC Class B certified and having an IP50 rating for water and dust resistance, Avalue EPS-ADS possesses outstanding industrial-grade reliability. Not only is it highly effective in applications such as automated warehousing and logistics operations, AI inspection equipment, automated robotic assembly and automated production lines, but it can also be used for automated payment at airports, hotels and malls, and integrated into robot guide or usher. With its wide variety of I/O ports for flexible expansion, high-speed Wi-Fi and 5G transmission, and compact size and easy installation, Avalue EPS-ADS fanless rugged system is your best choice for industrial-grade embedded solution.
