Submersible Molex MX150 Headers Afford Superior Sealing and Electrical Performance

Advanced sealant design reduces cost and simplifies wire-to-board connections in high temperatures



“Designed for automotive and commercial vehicles, recreational vehicles, construction equipment, and marine applications, MX150 headers expand on the Molex portfolio of automotive and industrial solutions,” states Corey Schroeder, Industry Marketing Manager, Molex. “In wire-to-board configurations, the preassembled, submersible MX150 system simplifies device tooling by incorporating USCAR-specified interface geometry directly into the sealed headers.”



MX150 Connector Key Features

Rugged, environmentally sealed connector system supports both low-level signal and power applications up to 22.0A

PCB board alignment and retention features simplify header placement and retention

Sealing geometry incorporates spray shield to meet IP6K7 and IP6K9K requirements

A true sealed connector system, the MX150 header system has been tested and confirmed to perform under submersed conditions in various fluids

High-performance MX150 connector system in reduced package size – ideal for SAE-style wire in challenging applications



The economical MX150 connector system features all-in-one plug and receptacle housings with pre-assembled, wire and interfacial connector seals. The solder-tail and compliant-pin electrical interfaces provide module design flexibility and lower applied costs by eliminating the need to purchase, handle and crimp individual wire seals. Integral terminal position assurance (TPA) and optional connector position assurance (CPA) components allow simple terminal insertion and secure seating to prevent accidental disengagement during high vibration and severe shock applications. Plastic seal plugs facilitate sealing of unused circuits. And, easy terminal extraction and insertion enable quick, low-cost field repairs.



Integral, two-way matte and interfacial Molex MX150 header seals conform to IEC IP67 and SAE USCAR-2, Rev 4 standards and are rated for use in on-engine, high vibration, under-hood and under-chassis environments at class 3 (-40 to +125°C) operating conditions. Molex manufacturing facilities are ISO9000 and ISO14000 certified.
