SPDT switch covers 2.4 to 8.3 GHz

26th October 2023
Mick Elliott
0

Richardson RFPD has announced availability and full design support capabilities for a single-pole, double-throw switch from Skyworks Solutions.

The SKY59608-711LF SPDT uses advanced switching technologies to maintain low insertion loss and high isolation for all switching paths.

The high-linearity performance and low insertion loss achieved by the SKY59608-711LF make it an ideal choice for low-power transmit/receive applications.

Key features of the SKY59608-711LF include:

  • Frequency range: 2.4 to 8.3 GHz
  • Insertion loss: 0.75 dB typical @ 5 to 7 GHz
  • Isolation: 23 dB typical @ 5 to 7 GHz
  • 0.1 dB Input Compression Point (IP0.1dB): +31 dBm
  • Single control logic
  • 1.1 V and 3.6 V logic compatibility
  • Supply voltage range: 2.7 to 5 V
  • Switching time: 200 nS
  • Package: Ultra-miniature, MLPD (6-pin, 1.1 mm x 0.7 mm x 0.45 mm) (MSL1, 260 °C per JEDEC J-STD-020)

The SKY59608-711LF is intended for mode-switching in WLAN applications. It is part of Skyworks’ Sky5 product portfolio that streamlines 5G architectural complexities with highly integrated transmit/receive front-end solutions and diversity receive (DRx) modules.

Specifically designed for new spectrum in the sub-6 GHz range, the Sky5 products offer a MIPI interface, are baseband-agnostic and comply with 3GPP standards.
