Isolation
UCC21520DW
Texas Instruments
Price range: $2.44 - $65.98
Category: Isolation
MOSFET DRVR 6A 2-OUT Hi/Lo Side Non-Inv 16-Pin SOIC W T/R
UCC21520DW Inventory
by: Texas Instruments
Distributor
SKU
Stock
Cost
Jak Electronics
UCC21520DW
734
$65.98
Parameters
Prop Delay(Max)(ns)
30
Package Group
SOIC
Input VCC(Min)(V)
3
Peak Output Current(A)
6
UL 1577 Isolation Voltage (Single)(Vrms)
5700
DIN V VDE V 0884-10 Surge Voltage Rating(Vpk)
8000
Package Size(mm2=WxL)
16SOIC
Prop Delay(ns)
19
DIN V VDE V 0884-10 Working Voltage(Vpk)
2121
Approx. Price (US$)
2.40 | 1ku
Output VCC/VDD(Max)(V)
25
Power Switch
MOSFET
DIN V VDE V 0884-10 Transient Overvoltage Rating(Vpk)
8000
Output VCC/VDD(Min)(V)
9.2
Number of Channels(#)
2
Operating Temperature Range(C)
-40 to 125
Input VCC(Max)(V)
18
Features
Part Family
UCC21520
Status
ACTIVE
ROHS
Compliant
PB Free
Yes
