Amplifiers
UA741CPSR
Texas Instruments
Price range: $0.11 - $0.26
Category: Amplifiers
UA741 General-Purpose Operational Amplifier
UA741CPSR Inventory
by: Texas Instruments
Parameters
Total Supply Voltage(Max)(+5V=5, +/-5V=10)
36
Architecture
Bipolar
Approx. Price (US$)
0.11 | 1ku
Total Supply Voltage(Min)(+5V=5, +/-5V=10)
7
Output Current(Typ)(mA)
25
Iq per channel(Typ)(mA)
1.7
Offset Drift(Typ)(uV/C)
0
Rating
Catalog
Operating Temperature Range(C)
0 to 70
IIB(Max)(pA)
500000
Additional Features
Vos Adj Pin
CMRR(Typ)(dB)
90
Package Group
PDIP,SO,SOIC
Number of Channels(#)
1
Vos (Offset Voltage @ 25C)(Max)(mV)
5
Vn at 1kHz(Typ)(nV/rtHz)
20
GBW(Typ)(MHz)
1
CMRR(Min)(dB)
70
Package Size(mm2=WxL)
8SOIC
Iq per channel(Max)(mA)
2.8
Slew Rate(Typ)(V/us)
0.5
Features
Part Family
UA741
Status
ACTIVE
ROHS
Yes
PB Free
Yes
