Isolation
ISO35TDW
Texas Instruments
Price range: $0.00 - $13.97
Category: Isolation
Single Transmitter/Receiver RS-485 16-Pin SOIC Bulk
ISO35TDW Inventory
by: Texas Instruments
Distributor
SKU
Stock
Cost
Parameters
CSA Isolation Rating(Vrms)
3000
Package Group
SOIC
VCC1(Min)(V)
3
CSA 61010-1 Basic Working(Vrms)
600
VCC2(Max)(V)
3.6
Operating Temperature Range(C)
-40 to 85
Duplex
Full
Datarate(Mbps)
1
VCC2(Min)(V)
3
Fail Safe
Idle,Open,Short
DIN V VDE V 0884-10 Transient Overvoltage Rating(Vpk)
4242
UL 1577 Isolation Voltage (Single)(Vrms)
2500
Package Size
mm2
Integrated Transformer Driver
Yes
CSA 61010-1 Reinforced Working(Vrms)
150
VCC1(Max)(V)
3.6
DIN V VDE V 0884-10 Working Voltage(Vpk)
566
Approx. Price (US$)
3.25 | 1ku
CSA 60950-1 Basic Working(Vrms)
760
ESD(kV)
16
Number of Nodes
256
DIN V VDE V 0884-10 Surge Voltage Rating(Vpk)
4000
Features
Part Family
ISO35T
Status
ACTIVE
ROHS
Compliant
PB Free
No
