Premier Magnetics' chokes with integrated magnetics

The PM-CMCX5 Series devices’ performance features include strong winding-to-winding insulation (5KV), wide operating temperature (-60°C to 155°C) and low-capacitive coupling to the core. Excellent mechanical stability is achieved utilising Premier Magnetics’ proprietary Snap-In technology to secure parts to the pc board without the use of epoxy during the assembly process.

The new PM-CMCX5 Series offers 16 models with a selection of spread or compressed windings and common mode choke inductances from 0.5 to 30mH. The data sheet includes a part-number chart providing details on differential mode inductances, typical current to cause a temperature rise of 70°C (IDC), DC resistance (DCR), and self-resonant frequency (SRF).

“Our new highly integrated, high-performance CM Guard Series provides common mode and differential mode attenuation in a single device. They can serve to reduce the number of components in a filter assembly,” said Premier Magnetics President, Dennis Earley. “Using our unique Snap-In technology, they also simplify and speed up product assembly by eliminating time-consuming epoxy application.” Earley added, “Over the coming year we’ll expand the CM Guard Series portfolio to provide models with higher DM inductance, higher temperature stability, and reduced size.”
