Ebflow technology speeds up small nuclear reactor production

In a trial conducted by Sheffield Forgemasters, Cambridge Vacuum Engineering’s Ebflow technology was deployed to cut the amount of time needed to weld a small modular reactor (SMR) pressure vessel demonstrator from more than a year, to less than 24 hours – a move that could help reshape the future of nuclear reactor production worldwide and bridge the gap in the UK’s energy market.

As part of a Government-funded project, Sheffield Forgemasters incorporated Ebflow, operating under local vacuum, into a bespoke, large-scale EB facility at its Brightside Lane site to complete four thick nuclear grade welds on vessels with a diameter of three meters and a wall thickness of 200mm. As well as reducing welding time by an astounding 99%, Ebflow also delivered the superior quality and precision of welds needed to ensure SMRs operate safely – setting a new standard for weld-joining thick-walled components.

Ebflow is a highly advanced fusion welding process with applications across a wide range of industries from oil and gas to nuclear power generation to ship building and more. The technology utilises a focused beam of high-velocity electrons to join metal components together. The main difference to traditional welding methods is that no third-party material is introduced to make the join. This technique enables unparalleled levels of accuracy and efficiency, making it ideal for the intricate welding requirements of primary components used in mission-critical energy applications – including mini nuclear reactors.

Bob Nicolson, Managing Director at CVE, said: "Our partnership with Sheffield Forgemasters demonstrates the power of Ebflow and proves – beyond doubt – the benefits it can deliver when it comes to driving sustainable advancements in the energy sector. We all know the clock is ticking when it comes to climate change. As more governments worldwide sign up to net zero emissions by 2050, the energy industry must embrace technologies – like Ebflow – that can help speed up the deployment of low carbon energy production.”

Sheffield Forgemasters is the only company in the UK with the capability to manufacture the large forgings required for SMRs, and now – thanks to Ebflow - it has years of developmental lead on global competitors in welding thick-walled assemblies.

Dr Michael Blackmore, Senior Development Engineer and Project Lead at Sheffield Forgemasters, said: “The implication of industrialised Electron Beam Welding technology within the nuclear industry is monumental, potentially taking high-cost welding processes out of the equation.”

Professor Jesus Talamantes-Silva, Research, Design and Technology Director at Sheffield Forgemasters, said: “We are delighted to have reached a significant milestone in assembling a nuclear vessel demonstrator, using electron beam welding for the first time at this scale, with 100% success and no defects.”

Dr Jacob Pope, Development Engineer and LEBW machine tool installation lead at Sheffield Forgemasters, said: We thank the Government’s Department for Energy Security and Net Zero for enabling the project through its Nuclear Innovation Programme. We also thank our esteemed partner, Cambridge Vacuum Engineering, for their invaluable support throughout this endeavour. Their remote and on-site assistance played an instrumental role in the success of this project.”

Ebflow is the result of years of research and development by specialists at CVE, which is headquartered in Cambridge, UK and has regional offices in Beijing, China, and Massachusetts, USA, as well as a global network of agents.
