Rohde & Schwarz ready range of solutions for electronica

A variety of applications based on its next-generation oscilloscopes of the MXO 5 and MXO 5C series will be showcased. These instruments assist engineers to ensure the reliablity of their power electronics. The eight-channel MXO 5 oscilloscope coupled with the R&S RT-ZISO isolated probing system delivers unparalleled accuracy, sensitivity, dynamic range and bandwidth. With these features it is the ideal solution for characterization, verification and debug of the next generation of wide-bandgap (WBG) power designs with SiC and GaN, demonstrated at the event.

In another setup, the MXO 5 oscilloscope will demonstrate that multi-phase buck converter design validation can be easy and delivers reliable results. High-speed multi-phase buck converter SoCs offer various operational benefits to meet demands in big data and other applications requiring lower voltages, higher currents and faster switching times.

And in a demonstration in partnership with PE Systems visitors will be able to experience a double pulse tester system employing the new rackmount optimized MXO 5C oscilloscope without a display along with probes and power supplies from Rohde & Schwarz. The fully automated test system for characterizing power conductors and passive components allows the user to search for optimal driver parameters and conduct verification measurements on entire power electronic systems.

To verify the system level performance of RF frontends across different impedances, Rohde & Schwarz will present a new solution for wideband modulated load pull, using the R&S SMW200A vector signal generator, the R&S RTP164 oscilloscope and new software option R&S RTP-K98 to characterize non-linear devices fast and precisely. With this solution users can validate RF frontends for load impedance variation as seen when driving RF signals into an antenna over a wider frequency range.

For both device developers and conformance test houses, the R&S EPL1000 EMI test receiver offers fast, accurate and reliable EMI compliance measurements up to 30 MHz and fully complies with CISPR 16-1-1.

The R&S EPL1000 features 4-channel click rate analysis, a real-time spectrogram function and automated measurements, making it ideal for conducted voltage and current measurements. Typical applications include pre-compliance measurements, pre-certification and certification in line with IEC, EN, CISPR and FCC.

The new R&S RadEsT automotive radar tester is an ultra-compact, versatile radar target simulator that meets the full range of testing needs – from lab-based functional testing to vehicle-level production checks and beyond. Visitors can learn how to streamline radar sensor testing using the R&S RadEsT in radar sensor calibration, ADAS/AD functional testing and on OEM production lines.

 Even marginal improvements in electric drivetrain efficiency and performance can significantly enhance overall electric vehicle (EV) operation. At electronica, Rohde & Schwarz will present a solution for OEMs and their suppliers to characterize and optimize drivetrain components, such as inverters and battery management systems. The solution is based on the MFIA from Zurich Instruments, the MXO 5 oscilloscope and the R&S NGM power supply.
