EnOcean deal bolsters Mouser’s IoT armoury

EnOcean’s family of tools and interfaces for Smart Building applications simplifies the commissioning and integration of control networks in IoT systems based on the ISO/IEC 14908-1 Local Operating Network (LON) protocol and other open standards.

The companuy provides solutions that facilitate integration of LON devices with energy harvesting EnOcean devices for building automation, smart homes, lighting control, industrial applications, and more.

LON network design is made easier using the new EnOcean Izo Commissioning Tool (CT), available at Mouser Electronics. It allows designers to draw networks using the integrated Microsoft Visio tool, automatically configuring communication with LON devices and matching their configuration to the drawing.

The result is a network drawing that becomes the "as-built" documentation for the network that is a critical deliverable from the building integrator to the building owner. IzoT CT integrates any LON devices including LON/IP, LON/IP-852, LON/IP-FT, LON/IP-TP-1250, LON-FT, LON-TP-1250, and LON-PL devices.

The EnOcean U60 FT and U60 TP-1250 DIN USB network interface expansion modules enable a SmartServer edge server, embedded controller, or computer to communicate with LON free topology (FT) or 1.25 Mbps (TP-1250) twisted-pair networks via USB.

These modules facilitate communication with everyday devices like pumps, motors, valves, sensors, actuators and lights for lighting controls, building automation, energy management, transportation systems control and telecommunications equipment management.  The U60 compact devices are available in DIN 43880 2TE-compliant enclosures and interface with LON/IP-FT, LON/IP-TP-1250, LON-FT, and LON-TP-1250 networks.

EnOcean U60 FT USB network interface modules allow an embedded controller or computer to communicate via USB with LON/IP-FT and LON-FT networks.

These compact boards include network and USB pin headers for quick integration into any controller or device. The source code for LON/IP protocol stacks and U60 drivers is available at no charge from EnOcean at www.github.com/izot.

The EnOcean U70 PL-20 USB network interface expansion module allows a SmartServer edge server, an embedded controller, or any computer to communicate via USB with LON PL-20 power line carrier networks. The U70 facilitates communication with everyday devices communicating via power line networks such as street light controls for Smart City applications. The U70 PL-20 compact module is engineered in DIN 43880 7TE compliant enclosure compatibles.
