Panel PC is designed for harsh environments

14th December 2023

Mick Elliott

0 0

Avalue Technology’s ARC-1037 next-generation rugged panel PC, is now available from distributor Solsta.

Powered by the latest generation Intel Atom Alder Lake-N processor, the ARC-1037 features a vibrant 10.4-inch 1024×768 LED panel with an impressive 50,000-hour lifespan, ensuring lasting clarity and visual performance durability. The 5-wire resistive touch screen ensures a responsive and intuitive user experience.

For added versatility, a USB Type C port with Power Delivery (PD) capabilities (20V/3A) supports USB 3.2 (gen2, 5V/3A) and DP display functions.

Connectivity is the heart of the ARC-1037’s design; two 2.5 Gigabit Ethernet ports meet high-speed networking requirements, while the wireless aspect supports high-speed, low-latency technologies such as 5G modules and Wi-Fi 6.

The rich I/O design offers 2 x COM ports and 2 x USB3.2 gen.2 (10Gbps) ports for efficient data transfer, and built-in 2W speakers enhance audio capabilities.

The ARC-1037 is resistant to water, dust, and shock and is engineered to excel in high humidity, high temperature, and high vibration conditions.

It suits applications such as industrial automation, rehabilitation equipment, and automated kiosks.

IP-65 water and dust resistance, wide operating temperature range, and sunlight readability all position the ARC Series as the ultimate solution for both indoor and outdoor applications.

Simple mounting mechanisms and panel mounting kits facilitate use in a variety of applications.

Optional optical bonding and coating technologies (such as anti-glare, anti-reflective, anti-UV/IR) are available to address the display challenges found in outdoor displays, mobile devices, vehicle systems, defence applications and industrial environments.

ARC Series products support Avalue’s proprietary IET modules, continuing the legacy of ruggedness and expandability.

These modules offer a range of I/O options such as isolation COM, CANbus, GPIO and USB based on budget and specification.

The flexibility of IET technology allows specific modules to be designed to meet unique requirements, balancing size, performance, and expandability.
