MPT-7100V rugged in-vehicle computer

Engineered with the 13th Gen Intel Core processor, this device can operate in extreme temperatures ranging from -40°C to 70°C. Its fanless aluminium chassis ensures durability, providing resistance against shock, vibration, and dust.

Equipped with robust M12 and FAKRA connectors for secure communication, the MPT-7100V integrates seamlessly with vehicle control systems through isolated CAN 2.0/FD ports. This advanced CAN FD technology enables faster, more efficient data transfers, essential for modern vehicle ECUs. The system also boasts dual SIM sockets for reliable mobile broadband connectivity, crucial for real-time communication and data processing.

The device offers substantial storage solutions with dual 2.5" SSD bays supporting up to 5TB and RAID configurations, alongside an M.2 M-key slot for high-speed NVMe storage. For further functionality, it features a USB Type-C port supporting Alternate Mode and 60W Power Delivery for efficient power management and device charging. It is E-mark certified, adhering to European vehicle regulations, and incorporates Trusted Platform Module (TPM) technology for secure operations.

Combining ignition control and a wide voltage input range (9V to 36V DC), the MPT-7100V is a robust solution for telematics, fleet management, surveillance, and other mission-critical tasks in demanding environments. Its extensive I/O capabilities and support for AI-driven applications ensure adaptability and future-proof performance across a range of automotive applications.

MPT-7100V features:

• Robust M12 & FAKRA connectors with rich I/O interface
• Dual SIM sockets support WWAN redundancy
• Onboard isolated CAN 2.0A / 2.0B / CAN-FD
• Full car battery Ignition power control
• Two removable 2.5” device bay for SSD storage
• Rich I/O interfaces for wireless, SSD, GPS, WWAN and add-on card expansion
• Wide-range voltage GPIO interface
• 1x USB Type-C with graphics output for quick setting and diagnostics
• Fanless and ruggedised design
